DIGITAL GLASS
LARGE FORMAT REAR PROJECTION SCREENS

Large Format Digital Glass is the next generation screen technology, manufactured using a special process that coats our advanced optical projection layer directly onto tempered or laminated glass or acrylic. The rear projection layer itself is our new optical coating, offering high brightness and unsurpassed contrast even in brightly lit environments. This unique screen technology has been developed to work specifically with ultra short throw projectors as when as standard projection applications, spreading the light evenly into each corner without creating hot spots.

Digital Glass is available in panel sizes up to 315 x 118",  providing an extremely robust solution for digital signage, high-end projection / presentation screens and large format edge blending solutions.  This optical screen technology is suitable for FHD / 4K / 8K projection, making it a much more cost effective than high resolution LCD / LED video walls.  The polished edges of each Digital Glass panel enable multiple screens to be installed side-by-side, creating huge seamless Video Projection Walls and/or Virtual Projection Rooms / Caves.

Custom glass screen sizes and thicknesses are available on request, along with lightweight acrylic options. Digital Glass can also be combined with
Large Format Interactive Touch Frames  to create Interactive Digital Glass – perfect for large format multi-touch display applications.


Rear Projection

UST REAR PROJECTION
Due to the screen's special optical surface 'Digital Glass' can utilise Ultra Short Throw (UST) Rear Projection and so these vast screens only require a  limited amount of space behind for projectors, making them a great high impact and cost effective solution.


RESOLUTION
These large format projection screens are the ideal alternative to expensive high resolution Indoor LED Screens as Digital Glass Rear Projection Screens produce stunning HD/4K/8K content at a fraction of the cost an LED Screen and individual Digital Glass Screens are available in sizes up to 8.75 yards x 3.28 yards.

187 (2).png

INTERACTIVE OPTION

Touch screen option available utilising our Large Format Interactive Touch Frames


RIGID LARGE FORMAT REAR PROJECTION SCREENS

SPECIFICATIONS

Neutral-Grey or Pearl White (Glass or Acrylic Screens)

Ultra Short Throw Projection Peak Gain 0.45 - 0.65

Viewing Angle 140 - 160 degrees

High Quality Video and Presentation Screens

Optical Screens Suitable for Edge Blending

Superior FHD / 4K / 8K  image quality

Custom Screen Sizes and Aspect Ratios

Untitled design (3).png
Untitled design.png

TYPICAL APPLICATIONS

Auditoriums and Boardrooms

Exhibitions and Conferences

TV Studios and Control Rooms

Department Stores and Malls

Airports, Trains and Bus Stations

Museums and Visitor Attractions

Virtual Rooms and Caves

picture 10.jpg

GLASS SCREENS

STANDARD SCREEN SIZES

32 (1)_edited.png

80"

69.70" x 39.20"

16:9

32 (1)_edited.png

100"

87.20" x 49.00"

16:9

32 (1)_edited.png

120"

104.60" x 58.80"

16:9

LIGHTWEIGHT ACRYLIC GLASS SCREENS

32 (1)_edited.png

220"

191.70" x 107.90"

16:9

32 (1)_edited.png

240"

209.20" x 117.70"

16:9

32 (1)_edited.png

250"

241.00" x 68.00"

32:9

32 (1)_edited.png

160"

137.80" x 77.50"

16:9

Untitled design (2).png
32 (1)_edited.png

140"

122.00" x 68.60"

16:9

32 (1)_edited.png

180"

156.90" x 88.20"

16:9

32 (1)_edited.png
32 (1)_edited.png

279.00" x 79.00"

32:9

313.00" x 88.00"

32:9

290"

325"

32 (1)_edited.png

200"

174.30" x 98.10"

16:9

32 (1)_edited.png

181"

174.00" x 49"

32:9

32 (1)_edited.png

217"

209.00" x 59.00"

32:9

*Custom screen sizes available upon request

ACCESSORIES

UST LASER PROJECTOR

Digital Glass works perfectly with our lamp free VISIONAIR-E® ultra short throw laser projector.

INFRARED MULTI TOUCH FRAME

Digital Glass can also be combined with VISIONAIR-E’s infrared multi touch frames to create Interactive Digital Glass – perfect for large format multi-touch display applications.
